LAMBDA touch peristaltic pumps

LAMBDA touch peristaltic pumps

LAMBDA touch programmable peristaltic pumps feature a built-in, user-friendly interface for precise, contamination-free liquid handling. Ideal for sterile sampling, lab applications, bioreactors, and fermenters, they ensure accurate media addition, nutrient dosing, and fluid transfer. With intuitive controls, pre-set flow rates, extended tubing life, and low maintenance, delivers stable flow for many days.

LAMBDA touch Programmable Peristaltic pumps



Innovative Design for Long-Term Stable Flow Rates

Proven Reliability for Over 40 Years

How LAMBDA Peristaltic pump offers stable flowrate without tubing damage?

  • Revolutionary Roller System – Unlike conventional designs, LAMBDA pumps feature large-diameter bearings with glass beads, which reduce pulsation, friction, and mechanical stress on the tubing, enhancing pump efficiency.
  • Superior Tubing Longevity – The smooth-gliding bearing system removes the need for fixation clamps or stoppers, significantly extending tubing lifespan while maintaining a steady, accurate flow rate.
  • Optimized Pump Head Design – Eliminates the requirement for tubing clamps and specialized stoppers, ensuring seamless operation while minimizing the risk of tubing damage.





Flow Rates: From 0.009 ml/h to 60 l/h

LAMBDA PRECIFLOW, HIFLOW, MAXIFLOW, and MEGAFLOW touch laboratory peristaltic pumps function as stand-alone laboratory instruments or seamlessly integrate as remote-controlled peripheral devices.

Compact and User-Friendly Design: Ultra-Compact: Only 10 cm x 11 cm x 9.5 (10.3) cm, fits in your hand and is stackable.


Touchscreen Interface: 3.5” TFT IPS touch display for intuitive operation and real-time monitoring.


Advanced Connectivity: USB connection enables remote control, dosing program management, liquid library updates, and software upgrades.


5-Year Warranty on LAMBDA PRECIFLOW touch pumps


Industry-Leading Compactness: The smallest peristaltic pump in its class


Extended Tubing Life & Low Pulsation: Reduced wear and tear for long-term efficiency


Economical & Low Maintenance: Compatible with affordable tubing, eliminating the need for stoppers

The LAMBDA PRECIFLOW touch peristaltic pump is an investment that quickly pays off, offsetting costs after approximately 100 meters of tubing usage while reducing maintenance expenses.

Type: Microprocessor-controlled programmable laboratory peristaltic pump
Accuracy: ± 5%
Digital Speed: PRECIFLOW touch - 0–1000 rpm | HIFLOW touch - 0–2800 rpm | MAXIFLOW touch - 0–3200 | rpm MEGAFLOW touch - 0–3200 rpm
Flow rate: PRECIFLOW touch - up to 600 ml/h | HIFLOW touch - up to 3 l/h | MAXIFLOW touch - up to 10 l/h | MEGAFLOW touch - up to 60 l/h
Tubing type: Silicone tubing or other materials having similar elasticity. Approx. 1mm wall thickness (For MEGAFLOW touch - Approx. 2mm wall thickness)
Non-volatile memory: Up to 20 dosing programs & up to 32 fluid names
Operating pressure: Approx. 1.5 bar in clockwise direction; Approx 2.0 bar in counter-clockwise rotation
Motor: PRECIFLOW touch - Hybrid Stepper | HIFLOW touch - BLDC 30W | MAXIFLOW touch -BLDC 50W | MEGAFLOW touch -BLDC 90W
Gear ratio: PRECIFLOW touch - 100:1 | HIFLOW touch - 64:1 | MAXIFLOW touch -20:1 | MEGAFLOW touch -20:1
Interface (remote control): USB 1.1/2.0 & REMOTE (CAN BUS), RS-485 interface 0-10 V; 0-20 or 4-20 mA; ON/OFF; foot switch contro
Display: 3.5" TFT IPS with 320 x 240 pixels resolution Viewing angles ± 70°
Conformity: DIRECTIVE 2014/35/EU; DIRECTIVE 2014/30/EU
Technical Standards: EN 61010-1:2010/A1:2019/AC:2019-04, EN 61326-1:2013
Weight: PRECIFLOW touch - < 1 kg | HIFLOW touch - 1.2 kg | MAXIFLOW touch - 1.2 kg | MEGAFLOW touch - 2.5 kg |
Dimensions : 104.4 x 110 x 95 (103.3) mm (MEGAFLOW touch - 180 x 127 x 160 (169.5) mm)
Operating temperature: 0–40 ⁰C
Operating humidity: 0–90%, not condensing
Power supply: Plug-in power adapter 90–240V AC 50/60 Hz, barrel jack 5.5/2.1 PRECIFLOW touch - 12W (12V / 1A) | HIFLOW touch - 30W (12V / 2.5A) | MAXIFLOW touch - 50W (12V / 4.16A) | MEGAFLOW touch - 90W (12V / 7.5A)
Warranty: 5 years (2 years for HIFLOW MAXIFLOW, MEGAFLOW touch)
